Cooler U14 Multi Socket 1851/1700/AM5/AM4 Workstation Activ

item no.: A 2860

available soon

-- €

Multi Socket Intel LGA 1851/1700/ AMD AM5/AM4

For Tower PC and Workstations

Aluminum Stacked-fin with Heat Pipes directly contact CPU

Intel up to 253W TDP

AM4/AM5 up to 185W TDP

Fan with PWM Function

Screw Type

Disclaimer: All product specifications and product images are subject to change without notice

SPECIFICATIONS:

Application
CPU Socket	Multi Socket Intel LGA 1851/1700 AMD AM5/AM4
CPU	Recommend for Intel® Core 12th–14th generation Socket LGA1700/1851 and AMD® Ryzen Socket AM4/AM5 Processor
Solution	Active Cooler for Desktop PC and Workstations
Technical Data
Overall dimension	77.8 x 147 x 165 mm
Weight	600g
Heat Sink
Material	Aluminum Stacked-fin with Heat Pipes directly contact CPU
Fan
Fan Dimension	Ø 140 x 140 x 25.8 mm
Speed	At Duty Cycle 0~20%: 700±200 RPM At Duty Cycle 50%: 1000±10% RPM At Duty Cycle 100%: 1800±10% RPM
Bearing	2 Ball Bearing
Rated Voltage	12V
Power	At Duty Cycle 0~20%: 0.46W At Duty Cycle 50%: 0.65W At Duty Cycle 100%: 2.08W
Air Flow	At Duty Cycle 0~20%: 41.67 CFM At Duty Cycle 50%: 56.41 CFM At Duty Cycle 100%: 96.55 CFM
Noise Level	At Duty Cycle 0~20%: 21.9 dBA At Duty Cycle 50%: 25.4 dBA At Duty Cycle 100%: 32.7 dBA
Rated Static Pressure	At Duty Cycle 0~20%: 0.60 mm-H2O At Duty Cycle 50%: 1.00 mm-H2O At Duty Cycle 100%: 2.50 mm-H2O
Lead Wire Pin Out	Pin#1- (-) Pin#2-(+) Pin#3-(Tachometer/Signal output) Pin#4-(PWM)
Thermal grease	Pre-printed
