Cooler J21 AMD SP7 - 1U Active RoHS

item no.: A 2854

Not in stock

-- €

AMD® SP7

For 1U Server and Up

Copper Fin and Vapor Chamber

TDP 300W

Disclaimer: All product specifications and product images are subject to change without notice

SPECIFICATIONS:

Application
CPU	AMD®
Socket	SP7
Technical Data
Overall dimension	120.0 x 103.6 x 27.2 mm
Weight	605g
Screw Type	M3.5/M4
Installation torque	12.5–15.0 kg-cm (10.8–13.0 in-lbf)
Heat Sink
Material	Copper Fin + Vapor Chamber
Fan
Fan Dimension	Ø80 x 13 mm
Fan Type	Double Ball Bearing with PWM function
Rated Voltage	12V
Speed	At Duty Cycle 0~20% : 2000 ±200 RPM At Duty Cycle 50% : 5900 ±10% RPM At Duty Cycle 100% : 10000 ±10% RPM
Power	At Duty Cycle 0~20% : 1.44W At Duty Cycle 50% : 1.44W At Duty Cycle 100% : 42.0W
Air Flow	At Duty Cycle 0~20% : 7.54 CFM At Duty Cycle 50% : 17.8 CFM At Duty Cycle 100% : 26.25 CFM
Noise Level	At Duty Cycle 20% : 35.1 dBA At Duty Cycle 50% : 53.8 dBA At Duty Cycle 100% : 65.2 dBA
Air Pressure	At Duty Cycle 0~20% : 7.54 mm-H2O At Duty Cycle 50% : 41.3 mm-H2O At Duty Cycle 100% : 118.64 mm-H2O
Lead Wire Pin Out	Pin#1- Black(-) Pin#2- Yellow(+) Pin#3- Green(Tachometer/ Signal Output) Pin#4- Blue (PWM)
