JJ-N-29NVMC/GEN5 for 2 x 2,5" NVMe U.2 SSD / 1 x MCIOx8

item no.: A 2838

available soon

-- €

Half 5.25" Drive bay width size

For 2 x 2.5” GEN5 NVMe U.2 SSD

MCIO 8i connector x 1

Support U.2/U.3/M.2 (with M2U04)

Transfer Rate PCIe 3.0/4.0/5.0 - 32/64/128Gbps

4pin Power connector x 1

Metal key lock design

With vibration reducing springs on each HDD tray

Metal frame / Stainless & High-Grade, Heat-Resistant Thermoplastic (UL-94V0)

4020 cooling fan x 1

Not including 5.25" bracket mounting kit

SPECIFICATIONS:

Model Name	JJ-N-29NVMC
Form Factor	Half 5.25" Drive bay width size
Support HDD types	2 x 2.5” GEN5 NVMe U.2/U.3/M.2 SSD M.2 (with M2U04 adapter) 2230/2242/2260/2280 Supported height up to 15mm PCIe 3.0/4.0/5.0 - 32/64/128 Gbps U.2 GEN5 up to 32GT/s (depends on the environment)
Interface	MCIO 8x Connector x 1 Mini 4pin Power Connector x 1 3pin Cooling fan jumper x 1
Security Design	Triangle key lock
Material	Metal frame & handle
LED Indication	Power ON: Green HDD Access: Orange blinking
Fan	1 x 4020 Blower Fan
Colour	Black
Dimensions (LxWxH)[mm]	155.1 x 72.5 x 40.0mm
Weight	0.37Kg
