Cooler L34 Water Cooling Multi Socket for 2U&up

item no.: A 2827

Not in stock
-- €
send inquiry for this product
  • Description
  • Specs
  • Downloads
  • Related Products

  • For Intel and AMD
  • Support MAXIMUM POWER Intel – 300W /AMD – 205W
  • For 2U Server and up
  • Liquid Cooling Solution recommended for CPU:


    - Intel Socket LGA 1200/115x
    - Intel Socket LGA 1851/1700
    - Intel Socket LGA 1356/1366
    - Intel Socket LGA 2011/2066, Square ILM
    - Support maximum power: Intel 300W / AMD 205W
    - AMD Processor, Socket AM4 / AM5 / FM2+ / FM2 / AM2 / AM2+ / AM3 / AM3+ / FM1
    - With Maximum 6000rpm Fan Speed


  • Disclaimer: All product specifications and product images are subject to change without notice

    • SPECIFICATIONS:

    Application
    Socket All-in-one Liquid Cooler Recommend for
    Intel Socket LGA1851/1700/1200/115X/LGA2011/2066/Square ILM Mounting LGA1356/1366
    AMD Socket AM4/AM5/FM2+/FM2/AM2/AM2+/AM3/AM3+/FM1
    Solution 2U Server and up
    CPU Intel and AMD
    Technical Data
    Fan Dimension 80 x 80 x 38 mm
    Four fans
    Pump Power Consumption 7.2W
    Speed At Duty Cycle 20%: 1350 ± 200 RPM
    At Duty Cycle 50%: 3100 ± 10% RPM
    At Duty Cycle 100%: 6000 ± 10% RPM
    Rated Voltage 12V
    Bearing 2 Ball Bearing
    Air Flow At Duty Cycle 20%: 23.085 CFM
    At Duty Cycle 50%: 53.01 CFM
    At Duty Cycle 100%: 102.60 CFM

    Noise Level At Duty Cycle 20%: 24.77 dBA
    At Duty Cycle 50%: 42.82 dBA
    At Duty Cycle 100%: 57.16 dBA
    Heat Sink
    Air Pressure At Duty Cycle 0~ 20%: 1.152 mm-H2O
    At Duty Cycle 50%: 6.074 mm-H2O
    At Duty Cycle 100%: 22.752 mm-H2O
    CPU power
    power At Duty Cycle 20%: 1.20W
    At Duty Cycle 50%: 3.84W
    At Duty Cycle 100%: 22.8W
    Lead Wire Pin Out
    Lead Wire Pin Out
    Pin1- (-)
    Pin2- (+)
    Pin3- (Tachometer/Signal output)
    Pin4- (PWM Control)
    Life – Continuous operating under normal temperature (40°C or 104°F)
    70,000 Hours
