JJ-GP-101M2-Br M.2 NVMe PCIe Adapter for 1 x M.2 NVMe SSD
item number: A 2752
- With PCIe Full height adapter + Low profile bracket adapter
- PCIe Brackets with swap in/out tray for 1 x M.2 SSD
- For 1 x M.2 NVMe SSD (length 30/42/60/80mm)
- PCIe 3.0/4.0 x4 NVMe M.2 M key SSD
- Support 1 x PCIe 3.0 / PCIe 4.0 M.2 NVMe SSD with M key (PCIe 3.0/4.0 x4) or B+M Key (PCIe 3.0 x2)
- With triangle metal keylock design
- With anti-vibration springs on the tray
- Stainless frame/tray and aluminum front bezel
- LED x 1 : Power on : Blue & Accessing : Purple blinking
- Heat sink pad and aluminum heat sink cover
- Dim: 167.3mm x 120.8mm x 19mm [Full height bracket]
- Dim: 167.3mm x 84mm x 19mm [Low profile bracket ]
- Weight : 115g
NB: The Hot Swap function depends on the mainboard
JJ-GP-101M2-Br connects the M.2 via PCIe Bus but the NVMe hot-swap function in PCIe Bus ist still limited and depends on the mainboard.
Only when the PCIe Bus on mainboard provides the hotplug function, the JJ-GP-101M2-Br can support the hot swap function.
If NOT, please power OFF the system BEFORE swap in/out the installed NVMe M.2 SSD to avoid unexpected failure in the system.
If you need the hot swap function please refer to other models, or to the suggested NVMe HBA / RAID card information.
Product in stock
-- €
JJ-GZS-104E1Sr-LC/GEN5 for 4 x E1.S NVMe in half 5.25"/MCIO
item number: A 2845
- Power control 2 x MCIO x8 connectors
- Support GEN5
- Support 4 x E1.S NVMe SSD
- HDD Type 5.8/8.0mm (with Z-105A tray)
- HDD Type 9.5mm (with Z-109A tray)
- 1 x 2x4 power connector (Pitch 2.0)
- Liquid Cooling
- With anti-vibration spring design on each swapping carrier
- Aluminum frame with stainless tray
- Triangle Keylock design
- LED indication provided by the SSD
- Form factor: Half 5,25" drive bay width
- Dimension: 193.35 (L) x 72.4 (W) x 39.8 (H) mm
available soon
-- €
JJ-M2U03 / M.2 NVMe to U.2 SSD (SFF-8639) Adapter
item number: A 2785
- Converts M.2 NVMe SSD to 7mm 2.5" U.2 SSD
- Supports M.2 length: 2280 / 2260 / 2242 / 2230mm.
- Supports M-Key and M+B-Key
- Tool-les M.2 SSD installation design
- Support PCIe 3.0/ 4.0 upto 64Gbps
- 1 x SFF-8639 connector with U.2 pin-define
- Support hot-swap function (depending on host)
- Upper and lower thermal pads
- Aluminum cover
- Mounting the aluminum cover with only one screw
- Dimension: 100 x 69.9 x 7mm
Product in stock
-- €
JJ-N-49NVMC/GEN5 for 4 x 2,5" NVMe U.2 SSD / 2 x MCIOx8
item number: A 2835
- 1 x 5.25" Drive bay size
- For 4 x 2.5" NVMe U.2 HDD/SSD (up to 15mm height)
- MCIO 8i Connector x 2
- Transfer Rate PCIe3.0/4.0/5.0 32/64/128Gbps
- For SSD Type U.2 / U.3 (with Dual Mode)
- M.2 (with M2U04 adapter) 2230 / 2242 / 2260 / 2280
- 15pin power connector x 2
- Cableless HDD connection
- Incl. 40 x 40 x 20mm rear fans x 2
- Metal keylock design
- Aluminum body & stainless tray
- LED: Power On = Solid green / Orange blinking = Accessing
available soon
-- €
JJ-N-49NVMS for 4 x 2.5" NVMe U.2 SSD (SlimSAS) SFF-8654
item number: A 2813
- Form Factor: 1 X 5.25" Drive Bay
- For 4 x 2.5" NVMe U.2 HDD/SSD upto 15mm
- SlimSAS SFF-8654 Connector x 4
- 15pin power connector x 2
- For SSD Type U.2 / U.3 (with Dual Mode)
- M.2 (with M2U03 adapter) 2230 / 2242 / 2260 / 2280
- Transfer Rate PCIe3.0/4.0 32/64Gbps
- Cableless HDD connection
- Incl. 40 x 40 x 20mm rear fans x 2
- Metal keylock design
- Metal frame & stainless HDD Tray
- Easy drives swap in / out
Product in stock
-- €
JJ-GM3-102M2-Fr/Slimline SAS(SFF-8654) 1x3.5" for 2xM.2
item number: A 2784
- SlimSAS (SFF-8654) x4 connector x 2
- Support PCIe 3.0/PCIe 4.0
- Support GEN3 (32Gbps) and GEN4 (64Gbps)
- Small 4pin power connector x 2 + 2pin fan jumper x 1
- Tray: Slimline SAS x8 connector
- Support SSD length 30/42/60/80mm
- Tool-less installation, or build-in screw
- With heat sink & thermal pad and 6cm cooling fan
- Keylock design
Product in stock
-- €
JJ-N-49NVMe NVMe U.2 SSD (32Gbps) RoHS
item number: A 2705
- For 4 x 2.5" NVMe U.2 HDD/SSD (32Gbps)
- MiniSAS HD SFF-8643 Connector x 4
- 15pin power connector x 2
- Cableless HDD connection
- Incl. 40 x 40 x 20mm rear fans x 2
- Metal keylock design
- Metal frame & stainless HDD Tray
- Easy drives swap in / out
Product in stock
-- €
JJ-GZ5-108E1Sr-LC/GEN5 for 8 x E1.S NVMe in 5.25"/MCIO
item number: A 2844
- Power control 4 x MCIO x8 connectors
- Support GEN5
- Support 8 x E1.S NVMe SSD
- HDD Type 5.8/8.0mm (with Z-105A tray)
- HDD Type 9.5mm (with Z-109A tray)
- 2 x 2x4 power connector (Pitch 2.0)
- Liquid Cooling
- With anti-vibration spring design on each swapping carrier
- Aluminum frame with stainless tray
- Triangle Keylock design
- LED indication provided by the SSD
- Form factor: 1 x 5,25" drive bay width
- Dimension: 193.35 (L) x 145.8 (W) x 41.5 (H) mm
available soon
-- €
Cooler A49 AMD AM4/AM5 - 4U Active RoHS
item number: A 2777
- AMD® Ryzen Socket AM4/AM5
- For 4U & up
- Heatpipes with Aluminum Base and Aluminum Fin Stack
- TDP 170W
- With PWM function
- Disclaimer: All product specifications and product images are subject to change without notice
Product in stock
-- €
JJ-N-22SS 12G SATA/SAS for 2 x 2.5" SSD/HDD Mobile Rack
item number: A 2848
- 2 x 2.5" HDD (SSD*) aluminum mobile rack with keylock
- Enables 2.5" SATA/SAS HDD/SSD* to be fit in 1 x 3.5" standard form factor drive bay (floppy size space) in any desktop PC or rackmount chassis
- Reliable metal key lock to safeguard the HDD/SSD
- Support up to 9.5mm height
- Support SATAI/II/III and SAS I/II/III (12Gbps) HDD/SSD
- Cableless HDD connection
- Enhanced air flow design
- Can be mounted in horizontal or vertikal way Trayless design to enhance the airflow and high quality aluminum body to maximize heat sinking. An ideal solution for any floppy-swap-bay for high-end applications, SoHo and consumers. *SSD Solid State Drive (flash based drive)
available soon
-- €
JJ-N-19NVMe19 / 1 x 2,5" NVMe U.2 in 1 x 3,5" bay
item number: A 2786
- 8643)
- For 1 x 2.5” NVMe U.2 SSD (PCIe3.0/4.0 x4) U.2/U.3/M.2 (with M2U03 adapter) upto 15mm height
- For 1 x 3,5" Drive bay width size
- Support PCIe3.0/4.0 X4 upto 32/64Gbps
- MiniSAS HD (SFF-8643) connector x 1
- 15pin Power Connector x 1
- Metal key lock design
- Including 3,5" bracket mounting kit
- Can host M.2 NVMe SSD (needs optional adapter JJ-M2U03)
Product in stock
-- €
Cooler U8 Multi Socket 1700/1200/115x/AM5/4 Mini ITX Active
item number: A 2763
- Multi Socket Intel LGA 1851 / 1700 / 1200 / 115x / AMD AM5/AM4
- For Mini ITX & up
- Copper Base & Aluminum Fins with Heat Pipe Embedded
- Up to TDP 135W (Intel)
- Up to TDP 130W (AMD)
- Axial fan with PWM Function
- Disclaimer: All product specifications and product images are subject to change without notice
Product in stock
-- €
