NU-0526 micro ATX / mini ITX
- Ultra slim chassis for both micro ATX and mini ITX motherbord
- Thermally advantaged slim chassis with internal AC power supply or external AC adaptor
- Various configurations of front I/O access - including up to 4x USB 2.0 and HD audio
- Optional card reader support SD2 & MS2 memory
SPECIFICATIONS:
| Model Name: | NU-0526 |
| Drive Bays: | micro-ATX: 1 x Slim DVD + 2 x 2.5: HDD mini-ITX: 1 x Slim DVD + 2 x 2.5" HDD + 1 x 3.5" or 2.5" HDD |
| Front I/O Access | 2 x USB 2.0, 1 x High Definition Azalia Audio or 4 x USB (optional) |
| Mainboard: | mini ITX form factor (171.5 x 171.5 mm) micro ATX (243.8 x 243.8 mm) |
| Power Supply: | internal 180/220/270W 81.5 (W) x 40.5 (H) x 150 (D) mm or - External 80/100W DC-to-DC board with AC adaptor |
| Ventilation: | 1 x 60x20mm cooling fan |
| Colour: | black\silver |
| Chassis: | metal |
| Dimensions: | 69mm (W) x 318mm (H) x 260mm(D) |
| Weight N.W./G.W. : | 5.07 lb/ 2.3KG (without PSU) |
| Complies with: | RoHS, CE, and FCC |
